Seat and Suspension for Ford® New Holland®, Challenger® Tractor


Challenger® Tractors - 65, 65A, 65B, 65C, 65D, 65E

Ford®/New Holland® Tractors - 8670, 8670A, 8770, 8770A, 8870, 8870A, 8970, 8970A

- Grammer 731 Seat
- Grammer MSG85 Mechanical Suspension
- Seat Adapter Plate
- Wire Adapter
- Mounting Hardware
- Installation Instructions

- Durable black/gray matrix fabric covering
- Armrests
- Backrest extension for extra backrest height
- Shock absorber
- Mechanical suspension with suspension travel of 4.00"
- Fore/aft isolator
- Suspension stroke up to 7.00"
- Flip-handle weight adjustment from 110 to 285 lbs
- Weight indicator
- Three-position height adjustment of 3.00"
- Frame width of 11.75"
- Durable suspension cover to keep components free of dirt and dust

Make Sure it Fits! Select model to ensure correct fitment.

Includes 1-Year Warranty

Estimated shipping

Enter Zip Code


Seat and Suspension for Ford® New Holland®, Challenger® Tractor

  • Abilene, KS: In stock
  • Sioux Falls, SD: In stock

Need Help?Our Ag part experts are here to help

877-800-1238 Mon - Fri, 7:30 AM - 5:30 PM, CST

Product Details

When it comes to new seat options at Abilene Machine, we have several viable options in the Grammer family of award winning replacement seats →  742, 741 and 731.  What are the differences between the three seat tops you ask?  We’ll carefully go through the specifications of the 731 seat assembly from Grammer, below.

The 731 Black/Gray Matrix is an excellent option as a replacement seat to accompany the air suspension or mechanical suspension in your Case IH® tractor!  The 731 is a budget friendly option for a replacement seat.  We offer this seat top because we understand the high level of comfort that farmers and ranchers demand at an affordable price.

A 17.50” backrest and a 20.50” wide seat cushion separate this replacement seat from its close relatives, the 742 and the 741.  The seat provides maximum comfort with adjustable lumbar support and a backrest that reclines from -10° to +24°.  Folding armrests make entering and exiting the seat a breeze.

Abilene Machine has made it incredibly easy to install with our ‘Plug & Play’ system.  Your new tractor seat can be easily installed on a Grammer Suspension or your factory suspension with our installation kit.  Our kit allows you to plug the Operator Presence Switch directly into your machine without causing any damage by dangerously splicing into your wiring harness.

When it comes to managing your in-cab comfort, we hope you’ll give us, Abilene Machine®, a chance to exceed your needs with this replacement suspension.  We have several viable options within the Grammer family of award winning seating systems.

As far as suspension goes, there are 7 options to choose from.  Which system you choose should be based on what will fit in your machine (John Deere®, Case IH®, etc.) and what feature(s) you desire.  We will carefully go through the specifications and features of the MSG85, below.

Measuring the seat-well of your machine (the distance between the fenders) is a good start to determining what suspension is right for you and your tractor seat.  The MSG85 has a frame width of 11.75” x 15.25”.  If the dimensions of the MSG85 will fit your seat-well, the next thing to consider is if you desire a mechanical or pneumatic suspension.  The MSG85, a mechanical suspension, is a very budget friendly option for a replacement suspension.  The MSG85 offers similar features and benefits to Grammer’s MSG95 (Pneumatic Suspension) at a significantly lesser price point.

There are two ways to adjust the ride, the Height Adjustment and the Flip-Handle.  To navigate through the 3 height settings, simply lift the seat upward until you hear it click.  That is the first setting.  If you continue to lift the seat, you will soon find the 2nd and 3rd setting.  Continuing to lift past the 3rd setting will reset the suspension back down to the 1st setting.  While sitting in your seat, rotate the Flip-handle to adjust the suspension and move the dial on the Weight-Indicator to the desired spot.

Please navigate through the links below for helpful videos from Grammer!


- Seat Back (17.50” tall)

- Seat Cushion (20.50” wide x 4.50” thick)

- Adjustable Lumbar Support (set to your desired preference)

- Adjustable Backrest (angles from -10° to +24°)

- Fore/Aft Adjustment (Slide rails allow the operator to slide the seat forward or backward in 0.50” increments)

- Adjustable/Foldable Armrest (all day comfort with convenience of folding out of your way when not needed

- Operator Presence Switch (plugs into your machine without modifying or damaging your wiring harness)

- Backrest Extension (adds up to 7.50” to the height of your backrest for extra support and



- Swivel rotates → ∓20°→  Allows operator to rotate seat either direction (AMSS11000) if installing on a Compact Suspension use swivel # (AM134958)

- Command Arm Bracket → A must have for any machine that is currently outfitted with a

command arm (if swivel is desired w/ C.A.B., must use swivel # AM134958)

- Side-to-Side Isolator → Control the horizontal movement of your seat giving you an increased level of connectivity for a more comfortable ride (AM1139345)

- Seat Belt → Meeting your safety standards for operating machinery (AM902133)

- Depth/Tilt→ Adjusting the height and angle of your seat cushion helps to alleviate strain on your knees (A different seat cushion must also be ordered to accommodate the cut-out for       handle)


Abilene Machine, LLC offers a standard 1-year warranty on all new, used and remanufactured parts. Abilene Machine reserves the right to inspect any or all parts returned for warranty before warranty claims will be honored. In all instances, Abilene Machine's sole liability will be either replacing the defective part or a refund not to exceed the purchase price of the defective part.

Read More

What it fits

Challenger® Tractors - 65, 65A, 65B, 65C, 65D, 65E

Ford®/New Holland® Tractors - 8670, 8670A, 8770, 8770A, 8870, 8870A, 8970, 8970A

How-to Videos

Installing a Seat Belt on a Grammer Seat
How to install a Swivel on a Grammer Mechanical or Air Suspension
Installing Side to Side Isolation on a Grammer Seat and Suspension Assembly
Operating your Weight & Height adjustment on a Grammer Air Suspension
